PMB Moisture Analyser

With simple operation and rapid response time, PMB moisture analysers offer the top value in their class. The automatic test-setting function enables easy recall for frequent testing of the same items without additional user programming. USB and RS-232 interfaces provide computer and printer connections to store test programs and results. No additional software is needed to take readings, giving users total freedom to collect data on a production floor or in the field. A single 400-watt halogen bulb heats samples in 1 °C selectable increments. Three heating options give users the flexibility to customise test methods and temperatures for different materials.
Features
Backlit display
Date
External calibration
GLP/ISO Print Reports
RS-232
Security lock down
Time
USB
Applications
Moisture determination
Weighing
Features and Benefits
Hardware
- Scratch-resistant aluminum housing protects internal components
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- Pan lifter allows easy placement and removal of samples
- RS-232 interface is available to provide speedy connection to computers and printers
- USB host for memory card and USB I/O interface
- USB interface included for data communication
- Temperature range 50°C to 160°C in one-degree increments
Software
- Three settings for heating sample include ramp-up, stepped temperatures and single temperature
- Seven preset drying modes allow test routines for several products
- Audible overload alarm warns when capacity is exceeded
- Testing can be set to start automatically when lid closes
- Calibration for temperature and weight
- Multilingual display allows use in many different countries
- Quick and easy configuration using the keypad
- Zero-tracking feature ensures display returns to zero reading
- Internal memory stores 49 different receipes and up to 99 test results,and additional test results and settings can be stored on a flash drive
Display
- Vivid, backlit LCD easily visible in any lighting conditions
- Programmable backlight can be set to "always on," "always off" or "light only when weighing"
- Capacity tracker built into display for easily monitoring possible overloads
Power
- Mains power cord
Models
Model | Capacity | Readability | Pan Size | Approvals | Request a Quote |
---|---|---|---|---|---|
![]() |
50g | 0.001g / 0.01% | 100mm ø | Request a Quote | |
![]() |
160g | 0.001g / 0.01% | 100mm ø | Request a Quote | |
![]() |
200g | 0.01g / 0.05% | 100mm ø | Request a Quote |
Downloads
Manuals
- Manual (English): PMB Moisture Analyser - PMB_UM_FULL_EN.pdf
- Manual (English): PMB Moisture Analyser - PMB_UM_EN.pdf
- Manual (English): PMB Moisture Analyser - PMB_Temp_Cal_UM_EN.pdf
- Manual (Deutsche): PMB Moisture Analyser - PMB_UM_DE.pdf
- Manual (Español): PMB Moisture Analyser - PMB_UM_ES.pdf
- Manual (Italiano): PMB Moisture Analyser - PMB_UM_IT.pdf
- Manual (中文): PMB Moisture Analyser - PMB_Short_UM_CN.pdf
- Manual (Français): PMB Moisture Analyser - PMB_UM_FULL_FR.pdf
Datasheets
- Datasheet (English): PMB Moisture Analyser - PMB-DS-A4-EN.pdf
- Datasheet (中文): PMB Moisture Analyser - PMB-DS-A4-CN.pdf
- Datasheet (Español): PMB Moisture Analyser - PMB-DS-A4-SP.pdf
- Datasheet (Italiano): PMB Moisture Analyser - PMB-DS-A4-IT.pdf
- Datasheet (Português): PMB Moisture Analyser - PMB-DS-A4-PG.pdf
- Datasheet (Deutsche): PMB Moisture Analyser - PMB-DS-A4-DE.pdf
- Datasheet (Français): PMB Moisture Analyser - PMB-DS-A4-FR.pdf
