Gladiator Washdown Scales: GGB 30M
Key Specifications
- Capacity
- 30kg
- Readability
- 0.01kg
- Repeatability
- 0.02kg
- Pan size
- 300x400mm
- Approvals
Featuring a combination of durability and performance, Gladiator scales accomplish washdown weighing tasks in demanding food, pharmaceutical and industrial settings. With an IP67 rating for washdown capabilities, Gladiator features easy-to-clean stainless steel construction that is ideal for wet and dusty environments. Connectors on the bottom are IP67-rated for thorough protection. Gladiator can expedite checkweighing tasks, with a large, backlit display that changes colour to show if the weight is over, under or within the set limit. The keypad is designed for maximum efficiency, with large, colour-coded tactile keys for fast recognition and easy operation. EC type approval means Gladiator is suitable for use in retail operations.
GGB 30M Specifications
- Capacity
- 30kg
- Readability
- 0.01kg
- Repeatability
- 0.02kg
- Weighing Units
- g, kg
- Calibration
- External calibration
- Stabilisation Time
- 2.0
- Pan Size
- 300x400mm
- Linearity
- 0.02kg
- Power Supply
- Internal rechargeable battery / Mains power cord
- Construction
- Stainless steel
- Interface
- RS-232
- Operating Temperature
- -10° to 40°C
- Display Digit Height
- 40mm
Features and Benefits
Approval
- EC type approved
- IP67-rated for protection against water and dust
Hardware
- Large, grade 304 stainless steel pan allows easy cleaning
- Rugged stainless steel construction for ultimate durability
- Heavy-duty rubber feet ensure stability of unit
- Sealed keypad protects against dirt and spills
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- RS-232 interface is available to provide speedy connection to computers and printers
Software
- External calibration allows for verification and adjustment with weights
- Hold function freezes the displayed weight, allowing time to elapse without losing the result
- Parts counting with preset sample sizes
- Selectable digital filtering for animal/dynamic weighing enables consistent results for moving subjects
Display
- Backlit display changes colour for quick notification of checkweighing limits
Power
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
Downloads
Manuals
- Manual (English): Gladiator Washdown Scales - Gladiator_UM_EN.pdf
- Manual (中文): Gladiator Washdown Scales - Gladiator_UM_CN.pdf
- Manual (Deutsche): Gladiator Washdown Scales - Gladiator_UM_DE.pdf
- Manual (Español): Gladiator Washdown Scales - Gladiator_UM_ES.pdf
- Manual (Français): Gladiator Washdown Scales - Gladiator_UM_FR.pdf
- Manual (Italiano): Gladiator Washdown Scales - Gladiator_UM_IT.pdf
Datasheets
Applications
Check counting- Checkweighing
- Display hold
- Parts counting
- Percentage weighing
- Weighing
Technical Highlights
- Backlit display
- Internal rechargeable battery
- Date
- GLP/ISO Print Reports
- Multiple weighing units
- RS-232
- Security lock down
- Tare Function
