GFK Floor Checkweighing Scales: GFK 300
With a full keypad that simplifies unit weight and sample entry, GFK floor scale capably performs checkcounting to a predefined weight or count. A durable stainless steel platform and pillar-mounted ABS plastic indicator make the GFK suitable for most counting and weighing applications. The large backlit display is visible in most settings and shows unit weight, total weight and number of pieces.
GFK 300 Specifications
- Capacity
- 300kg
- Readability
- 20g
- Repeatability
- 20g
- Weighing Units
- g, kg
- Calibration
- External calibration
- 00 Nav Number
- 1050010431
- Stabilisation Time
- 2.0
- Pan Size
- 400x500mm
- Linearity
- 40g
- Power Supply
- Mains power cord / Internal rechargeable battery
- Construction
- ABS plastic indicator with die-cast aluminum base
- Interface
- RS-232, Optional USB
- Operating Temperature
- -10° to 40°C
- Net Weight
- 12.5kg
- Dimensions Overall
- 400x620x860mm (wxdxh)
- Display Digit Height
- 20mm
- Battery Life
- 70.0
Features and Benefits
Hardware
- Adjustable levelling feet help optimise setup
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- Large, grade 304 stainless steel pan allows easy cleaning
- RS-232 interface is available to provide speedy connection to computers and printers
- Sealed keypad protects against dirt and spills
Software
- Audible overload alarm warns when capacity is exceeded
- Checkweighing with audible alarm
- Parts counting with freely selectable sample sizes
- Parts counting optimisation automatically refines piece weight as parts are added
- Preset tare function speeds the process of repetitive weighing
- Programmable for counting to a preset number of parts
- Selectable digital filtering helps minimise effects of vibration and disturbances
- Zero-tracking feature ensures display returns to zero reading
Display
- Vivid, backlit LCD easily visible in any lighting conditions
- Programmable backlight can be set to "always on," "always off" or "light only when weighing"
- Capacity tracker built into display for easily monitoring possible overloads
- Checkweighing LEDs clearly show under, over and acceptable limits
Power
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
Downloads
Manuals
- Manual (English): GFK Floor Checkweighing Scales - GK_GBK_GFK_UM_EN.pdf
- Manual (English): GFK Floor Checkweighing Scales - GBK_GFK_UM_EN.pdf
- Manual (中文): GFK Floor Checkweighing Scales - GFK_UM_CN.pdf
- Manual (Español): GFK Floor Checkweighing Scales - GBK_GFK_UM_ES.pdf
- Manual (Multi-Language): GFK Floor Checkweighing Scales - GBK-GFK-CM.pdf
Datasheets
- Datasheet (English): GFK Floor Checkweighing Scales - GFK-DS-A4-EN.pdf
- Datasheet (Français): GFK Floor Checkweighing Scales - GFK-DS-A4-FR.pdf
- Datasheet (Español): GFK Floor Checkweighing Scales - GFK-DS-A4-SP.pdf
- Datasheet (Italiano): GFK Floor Checkweighing Scales - GFK-DS-A4-IT.pdf
- Datasheet (Deutsche): GFK Floor Checkweighing Scales - GFK-DS-A4-DE.pdf
Applications
Check counting- Checkweighing
- Dynamic / animal weighing
- Parts counting
- Percentage weighing
- Weighing
Technical Highlights
- Backlit display
- Internal rechargeable battery
- Date
- External calibration
- RS-232
- Tare Function
- Time
